INOX DISTRIBUTOR FLOOR HEATING 7 CIRCUITS

Underfloor heating manifold made of NOX material for heating and cooling
Connection INOX manifold 4/4"
scale of adjustment valves: 0- 5
thermostatizable shut-off valves M30 x 1.5
connection circuits 3/4" euro-cone
maximum operating pressure: 10 bar
flow meters on the room, adjustable between 0 and 4.5 liters/min.
distance between the connections: 50 mm
maximum operating temperature: 70°C
delivered with 2 closing plugs 1"
Collecteurs pour chauffage et le refroidissement par le sol en NOX vannes de réglage : 0-5
vannes d\'arrêt thermostatiques M30 x 1.5
corcordement de circuits: 3/4" euro-cône
pressure maximal de fonctionnement : 10 bars
Sur le départ, débitmètre réglable, reglage between 0 and 4.5 liters/min.
distance between the connections: 50 mm
maximum operating temperature: 70°C
livré with 2 bouchons de fermeture 1"
Fußbodenheizungsverteiler aus Edelstahl zum Heizen und Kühlen
Anschluss IEdelstahl Verteiler DN25 (1")
Skala der Einstellventile: 0-5
Thermostatic Absperrventile M30 x 1.5
Anschlussreise: DN20 (3/4") Eurokonus
Maximum operating pressure: 10 bar
Durchflussmesser, einstelbar zwischen 0 und 4.5 l / min.
Abstand zwischen den Schlüssen: 50 mm
Maximum operating temperature: 70°C
Lieferung with 2 Verschlussstopfen 1"
Underfloor heating manifold made of NOX material for heating and cooling
Connection INOX manifold 4/4"
scale of adjustment valves: 0- 5
thermostatizable shut-off valves M30 x 1.5
connection circuits 3/4" euro-cone
maximum operating pressure: 10 bar
flow meters on the supply, adjustable between 0 and 4.5 liters/min.
distance between connections: 50 mm
maximum operating temperature: 70°C
delivered with 2 closing plugs 1"
